Uncompromising Security: MotionCam Outdoor HighMount (PhOD) Jeweller
, by Armia Ghali, 7 min reading time
Securing an outdoor area is always more challenging than securing an indoor space. It's often difficult to avoid blind spots or ensure the device doesn't cover unnecessary areas. Solutions that don't require constant maintenance, such as monthly battery changes, are invaluable. Finding the perfect solution may seem impossible, but Ajax makes it possible.
During the Ajax Special Event: Multiverse , revealed Ajax Systems MotionCam Outdoor HighMount (PhOD) Jeweller . With its wide coverage, advanced tamper protection, and thermal disruption filter, it is designed for simple and reliable outdoor security. The device can be installed at a height of 2 to 4 m. Installers are guaranteed to be pleasantly surprised by the new features and how easy it is to install.
Converting market needs into opportunities
Across Europe, especially in the DACH region and France, companies and property owners are increasingly opting for outdoor motion detectors with a higher mounting height. This growing demand is primarily driven by the needs of warehouses, construction sites, and factories, where traditional motion detectors are often unable to effectively detect threats. The main advantage of high-mounted motion detectors is their lack of a blind spot.
Ajax Systems recognized the market's needs and developed the MotionCam Outdoor HighMount (PhOD) Jeweller. Let's see what makes this device so special for commercial properties, private properties, and more.
Key features of the new motion detectors
All threats detected and verified
MotionCam Outdoor HighMount (PhOD) Jeweler is designed for installation at heights of 2 to 4 m. This allows them to detect motion in a large area. The detector has a detection range of up to 15 m With a 90° horizontal and vertical viewing angle, MotionCam Outdoor HighMount (PhOD) Jeweller prevents blind spots that burglars can use to break into a home or business.
The detector uses dual-motion detection technology. It combines two PIR sensors and a K-band microwave sensor so the device is activated when both sensors detect motion. The SmartDetect algorithm filters out potential false alarms, such as headlights, streetlights, or the heat of asphalt baking in the sun. This allows the detector to respond accurately to real threats.
MotionCam Outdoor HighMount (PhOD) Jeweller does not have pet immunity function.
Core for mobile alarm towers
The MotionCam Outdoor HighMount (PhOD) Jeweller is highly effective as the core of a security tower. It's an ideal solution for securing temporary locations such as construction sites, warehouses, event spaces, or other areas not connected to the power grid. Multiple detectors are mounted on a support structure for full 360-degree coverage. The motion detectors can be connected to Hub BP Jeweller , powered by an external battery, and combined with a outdoor siren . This creates a completely independent system for detecting intrusion and triggering an alarm. The Ajax Ready products already include several successful examples of such security towers developed in collaboration with our partners.
No need to worry thanks to alarm verification
When an intruder enters a protected zone, the system immediately sounds the alarm. Depending on the settings, the alarm is followed by a series of up to five photos. These images are displayed in the Ajax apps for users with appropriate access rights. The following types of photo verification are available:
- Photo by alarm : Images are automatically captured when motion is detected.
- Photo on schedule : images are taken at specific times.
- Photo by scenario : Images are captured when an alarm is triggered by a specific device in the system.
- Photo on demand : Photos can be taken at any time or when the system is armed.
Photo verification works best when the device is installed at an optimal viewing angle. A reliable mounting bracket is essential for maximum flexibility for the installer in correctly positioning the detector.
Hassle-free installation
The MotionCam Outdoor HighMount (PhOD) Jeweller installation process is as simple and intuitive as possible. These motion detectors are installed with a durable metal swivel mount.
In the Ajax PRO app, installers can check the camera's field of view and maximum detection zone using the Detection Zone option . This allows installers to take a test photo to check the camera's field of view. The test photo helps adjust the detector's tilt angle and horizontal position.
Advanced protection against sabotage
Tampering is one of the biggest threats to any security system. When one device is tampered with, the entire system can be compromised. That's why MotionCam Outdoor HighMount (PhOD) Jeweller features advanced tamper protection to stay one step ahead of intruders.
The device uses several layers of tamper protection:
- The magnetometer detects movement or attempts to move the device. If the magnetic field changes, it immediately sends notifications to users and the monitoring company.
- The tamper alarm is activated if the device is detached from the surface or if the integrity of the housing is compromised. The system immediately alerts the security company and users of an attempted break-in.
- The anti-masking system detects attempts to block the lens by painting over it, taping it over, or placing an obstacle in front of the detector's motion sensor.
- Regular polling ensures that the detector remains connected to the hub, and all data sent is encrypted.
Together, these measures provide comprehensive protection against sabotage, ensuring the system remains safe and operational at all times. As a result, MotionCam Outdoor HighMount (PhOD) Jeweller is certified according to European standards and complies with international security system standards such as EN 50131 and PD 6662:2017.
Excellent autonomy and stable performance in heat and cold
The detector operates for up to three years on its pre-installed batteries. This reduces maintenance and operating costs. It is also possible to connect an external 12–24 V⎓ power supply. When connected, the pre-installed batteries provide backup power, ensuring uninterrupted operation.
The detector operates in temperatures from -25°C to +60°C. It is effective in both extreme heat and cold. The IP55 housing protects the device from dust and water. The included hood provides additional protection against rain and snow. This makes the detector suitable for buildings exposed to harsh weather conditions.
Reliable wireless communication
Reliable long-distance communication is especially important for securing large or remote locations. As always, Ajax provides this as well. The MotionCam Outdoor HighMount (PhOD) Jeweller communicates with the hub at a distance of up to 1,700 m. This range is sufficient for large locations or warehouses. If more coverage is needed, the ReX 2 Jeweller signal booster can be used to double the communication range. The system maintains a stable connection even through concrete or steel structures.
MotionCam Outdoor HighMount (PhOD) Jeweller communicates with the hub via two secure radio protocols. The detector uses Jeweler to send alarms and events and Wings to send photos and update firmware. Both protocols use advanced encryption to prevent detector tampering. If someone attempts to disrupt or interrupt communication, the hub changes frequencies and notifies the monitoring center. Furthermore, MotionCam Outdoor HighMount (PhOD) Jeweller detects and reports any connection loss within seconds. Thanks to these features, users are guaranteed an effective security system in any situation.
