Voeding en PoE injectoren

Dahua, PoE-extender, 3 x RJ45 1 in , 2 out naar IPC of volgende extender max 2 in totaal). max 25w naar IPC in totaal , afmetingen: 79 x 52 x 23 mm, din rail montage / of in junction box PFT1300PoE Extender Features· Support passive PoE cascade power supply and Ethernetdata exchange· Support IEEE 802.3af/at standard power supply IP Camera· Cooperate with High PoE Midspan (PFT1200), able tocascade level 2 PoE Extender, connect to 3 IPC (total powerconsumption <=25W), max transmission distance 300m· 1*RJ45 10/100M PoE power supply input; 1*RJ45 10/100Msupply power for IP Cam; 1*RJ45 10/100M supply power forthe next extender· Installation mode: junction box internal mounting, DIN railmounting Technical SpecificationModel PFT1300Ethernet Port1*10/100 Base-T PoE power receiving port1*10/100 Base-T PoE power supply port, supplypower for the next extender1*10/100 Base-T PoE power supply port, supplypower for IPCTransmission DistanceCooperate with DH-PFT1200, able to cascadelevel two extender, connect to 3 IPC (level oneextender connects to 1 IPC, the OUT port of leveltwo extender and CAMERA port connect to 1 IPCrespectively, total power consumption <=25W),transmission distance is 300mPower Consumption <=3WApplication Humidity 10%~90%Working Temperature ﹣30°C~65°CWeight 57gDimension(W×D×H) 79mm×52mm×23mm

Lees meer minder

Dahua Midspan Hi-PoE, 75 W midspan , 802.3af, 802.3at, Hi-PoE, te gebruiken met oa. speeddome camera's, met power led indicator, kan op de muur gemonteerd worden TAM01GT01GT-7575W PoE Midspan  Features· Supports PoE for Hi-PoE 75W high power consumptionspeed dome· Indicator status: power (normal power on), PoE (normalpower supply)· Cooperate with PoE Extender (PFT1300), able to cascadelevel 2 PoE Extender, connect to 3 IPC, max transmissiondistance 300m· Wide working temperature: -30°C~ 65°C· Supports DoE Level VI· Lighting Protection: Level 4 Technical SpecificationModel TAM01GT01GT-75Ethernet Port 1*10/100/1000 Base-T1*10/100/1000 Base-T( PoE power supply)PoE Power Supply 802.3af, 802.3at, Hi-PoEPoE PIN Assignment 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)Indicator Power indicator, PoE status indicatorExchange Mode Store & forwardApplication Humidity 10%~90%Working Temperature -30°C~65°CWeight 250gDimension(W×D×H) 210mm×75mm×38.5mm

Lees meer minder

Dahua Midspan PoE, 30 W midspan , 802.3af, 802.3at, met power led indicator TAM1GT1GT-30PoE+ Midspan Features· Supports IEEE802.3af, IEEE802.3at standard· Conform IEEE802.3, IEEE802.3u and IEEE802.3ab standards· Wide temperature design: -10°C~55°C  Product OverviewTAM1GT1GT-30 is designed to work under extreme environments,such as wide temperature range and lightning environment. TheTAM1GT1GT-30 is single-port 802.3at PoE+ midspan with internal powersupply in compact housing. Carrying both Ethernet data and power, thedevice helps users to utilize just one Ethernet cable to easily install anddeploy IP camera, wireless AP or VoIP phone   Technical SpecificationModel TAM1GT1GT-30Ethernet Port 1*10/100/1000 Base-T1*10/100/1000 Base-T( PoE power supply)PoE Power Consumption Power output≤30WPoE Protocol IEEE802.3af, IEEE802.3atLED IndicatorPSE: Indicates the device is delivering power to thePD.(Green)PWR: Indicates the device is working properly.(Green)Application Humidity 10%~90%Power AC100~240V 50/60HzWorking Temperature -10°C~55°CWeight 250gDimension(W×D×H) 132.3mm×60mm×33mm

Lees meer minder

Dahua Voeding 12Vdc/2A DH-PFM320D-EN/BS/US 12V 2A Power Adapter FeaturesEasy installationWith indicator light workingSupport -30 ℃ ~+70 ℃ wide-range temperature operation, and the full load efficiency of the powersupply can be up to 100% at these temperaturesAccurate overcurrent, overvoltage protection Technical SpecificationsModel DH-PFM320D-EN DH-PFM320D-BS DH-PFM320D-US (VI)Electrical SpecificationInput 100~240V, 50/60Hz, 0.6AOutput 12V, 2A(+7% , -3%)Protection/EnvironmentalProtection Surge protection, over temperature protection, over current, voltage load protectionESD: EN61000-4-2± 4kV Contact; ± 8kV AirSurge: EN61000-4-5”Combination Wave: Common Mode ± 4KV (12 ohms);Differential Mode ± 2kV (2 ohms)Working Temperature -30℃~+70℃(-22℉~+158℉)Working Humidity <95% RHPhysical PropertiesWeight 170g(0.37lb)Dimension(Lxwxh) 104mmx45mmx33mm(4.09”x1.77”x1.3”)Installation Mode Plane installationColor BlackInput Plug 2-pin Euro plug 3-pin British plug 2-pin North American plugOutgoing Cord AC wire: 50cm(19.69”), DC wire: 80cm(31.5”)DC Plug Φ5.5mmxΦ2.1mmx12mm(Φ0.22”xΦ0.08”x0.47”)Safety StandardsCertification CE, FCC, UL-VIOrder InformationType Part Number DescriptionPowerDH-PFM321D-ENDC12V 1A Power Adapter_ Dahua brand, European standardDH-PFM321D-BSDC12V 1A Power Adapter_ Dahua brand, British standardDH-PFM321D-USDC12V 1A Power Adapter(VI)_ Dahua brand, North American standardDH-PFM320D-ENDC12V 2A Power Adapter_ Dahua brand, European standardDH-PFM320D-BSDC12V 2A Power Adapter_ Dahua brand, British standardDH-PFM320D-USDC12V 2A Power Adapter(VI)_ Dahua brand, North American standard

Lees meer minder

Dahua Voeding 12Vdc/1,5 A DH-PFM320D-015 DC12V1.5A Power Adapter FeaturesEasy installationSupport working with indicator lightSupport -30 ℃ ~+70 ℃ wide-range temperature operation, and the full load efficiency of the powersupply can be up to 100% at these temperaturesAccurate overcurrent, overvoltage protection Technical SpecificationsModel DH-PFM320D-015Electrical SpecificationRated input AC100~240V, 50/60Hz, 0.6AOutput voltage DC12V (+7%, -3%)Output current Max. 1.5A (+70℃)Protection/EnvironmentalProtection Surge protection, over temperature protection, over current, voltage loadprotectionESD: EN61000-4-2+/-6kV Contact; +/-8kV AirSurge: EN61000-4-5Combination Wave: Common Mode ± 4KV(12 ohms)Differential Mode ± 2kV(2 ohms)Working temperature -30℃~+70℃(-22℉~+158℉)Working humidity 5%~95% RHPhysical PropertiesWeight 95g(0.21lb)Dimension(LxWxH) 77.3mmx51.9mmx30.0mm(3.04”x2.04”x1.18“)Installation Plane installation, can be installed in junction boxes and wall mount bracketsColor WhiteInput plug 2-pin plug(L/N)Output plug 2-pin plug(+12V-)Safety StandardsCertification CE, FCCOrder InformationType Part Number DescriptionPower seriesDH-PFM320D-015 DC12V 1.5A power adapter(CE/FCC)DH-PFM321D-ENDH-PFM321D-BS DC12V 1A power adapter(CE/FCC/UL-VI) for camerasDH-PFM321D-USDH-PFM320D-ENDH-PFM320D-BS DC12V 2A power adapter(CE/FCC/UL-VI) for camerasDH-PFM320D-US

Lees meer minder

DH-PFM321: Voeding 12Vdc/1A FeaturesEasy installationWith indicator light workingAccurate overcurrent, overvoltage protectionSpecificationsModel PFM321GeneralInput AC100~240V,50/60Hz，0.5AOutput DC12V（﹢7%,-3%）--1A（±2%）Working temperature -30~70℃Working humidity ＜90%Weight 150gDimension 84mm×41mm×26mmInstallation mode Plane installationColor BlackOutgoing line length AC wire: 50cm, DC wire: 80cmCertification CE, FCC, CEC

Lees meer minder

Dahua, voeding voor muurmontage, AC90-264V input, DC12V 10A 9CH output DH-PFM342-9CH CCTV Distributed Power Supply Box Features· 9 Channel security camera power supply distribution box with individual LED output indicator and metal case by lockkey to prevent unauthorized access;· Wide voltage input: AC90~264Vac, meet the requirements in different parts for electric network fluctuation;· High quality and reliability: pass 100% quality examination and 3 months high temperature aging test;· With overload protection, over-current protection, over-voltage protection, anti-static and anti-interference ability;· Professional wall-mounted installation with reserved outlet holes, convenient and flexible.  Technical SpecificationElectrical SpecificationModel DH-PFM342-9CHInput Voltage Range AC90~264VOutputs 9 x 12VDC (-3%~+7%) outputsMax. output 10A, 120WOutput Protection 9 replacement fuses, max. per output 3AEfficiency 87%No Load Power Consumption <0.21WInternal ON/OFF Power Switch YesIndividual LED Output Indicator YesProtection/EnvironmentalSurge Protected Line to ground: 4000VLine to line: 2000VESD Contact discharge: 6000VAir discharge: 8000VWorking Temperature -20℃~+45℃(-4℉~+113℉)Working Humidity <90% RHPhysical PropertiesWeight 2.47kg(5.45lb)Dimension(LxWxH) 315mmx215mmx53mm (12.4”x8.46”x2.09”)Installation Wall mountColor WhiteSafety StandardsCertification CE(EN55032, EN55020)FCC(FCC Part 15 Class B, ISED ICES-003 Issue 6) Ordering InformationType Part Number DescriptionPower seriesDH-PFM340-5CH CCTV distributed power supply_Dahua brand, 5x0.8A, DC12VDH-PFM341-9CH CCTV distributed power supply_Dahua brand, 9x0.55A, DC12VDH-PFM342-9CH CCTV distributed power supply_Dahua brand, 9x1.1A, DC12VDH-PFM343-19CH CCTV distributed power supply_Dahua brand, 19x1.05A, DC12V

Lees meer minder

Dahua, voeding voor muurmontage, AC90-264V input, DC12V 4A 5CH output DH-PFM340-5CH CCTV Distributed Power Supply  Features· 5 Channel security camera power supply distribution box with individual LED output indicator and metal case by lockkey to prevent unauthorized access;· Wide voltage input: AC90~264Vac, meet the requirements in different parts for electric network fluctuation;· High quality and reliability: pass 100% quality examination and 3 months high temperature aging test;· With overload protection, over-current protection, over-voltage protection, anti-static and anti-interference ability;· Professional wall-mounted installation with reserved outlet holes, convenient and flexible.  Technical SpecificationElectrical SpecificationModel DH-PFM340-5CHInput Voltage Range AC90~264VOutputs 5 x 12VDC (-3%~+7%) outputsMax. output 4 AOutput Protection 5 replacement fuses, max. per output 2.5AEfficiency 84%No Load Power Consumption <0.5WInternal ON/OFF Power Switch YesIndividual LED Output Indicator YesProtection/EnvironmentalSurge Protected Line to ground: 4000VLine to line: 2000VESD Contact discharge: 6000VAir discharge: 8000VWorking Temperature -20℃~+45℃(-4℉~+113℉)Working Humidity <90% RHPhysical PropertiesWeight 0.85kg(1.87lb)Dimension(LxWxH) 165mmx165mmx50mm(6.5”x6.5”x1.97”)Installation Wall mountColor WhiteSafety StandardsCertification CE(EN55032, EN55020)FCC(FCC Part 15 Class B, ISED ICES-003 Issue 6) Ordering InformationType Part Number DescriptionPower seriesDH-PFM340-5CH CCTV distributed power supply_Dahua brand, 5x0.8A, DC12VDH-PFM341-9CH CCTV distributed power supply_Dahua brand, 9x0.55A, DC12VDH-PFM342-9CH CCTV distributed power supply_Dahua brand, 9x1.1A, DC12VDH-PFM343-19CH CCTV distributed power supply_Dahua brand, 19x1.05A, DC12V

Lees meer minder

Dahua, voeding voor muurmontage, AC90-264V input, DC12V 5A 9CH output DH-PFM341-9CH CCTV Distributed Power Supply  Features· 9 Channel security camera power supply distribution box with individual LED output indicator and metal case by lockkey to prevent unauthorized access;· Wide voltage input: AC90~264Vac, meet the requirements in different parts for electric network fluctuation;· High quality and reliability: pass 100% quality examination and 3 months high temperature aging test;· With overload protection, over-current protection, over-voltage protection, anti-static and anti-interference ability;· Professional wall-mounted installation with reserved outlet holes, convenient and flexible.  Technical SpecificationElectrical SpecificationModel DH-PFM341-9CHInput Voltage Range AC90~264VOutputs 9 x 12VDC (-3%~+7%) outputsMax. output 5 AOutput Protection 9 replacement fuses, max. per output 2.5AEfficiency 84%No Load Power Consumption <0.5WInternal ON/OFF Power Switch YesIndividual LED Output Indicator YesProtection/EnvironmentalSurge Protected Line to ground: 4000VLine to line: 2000VESD Contact discharge: 6000VAir discharge: 8000VWorking Temperature -20℃~+45℃(-4℉~+113℉)Working Humidity <90% RHPhysical PropertiesWeight 0.9kg(1.98lb)Dimension(LxWxH) 165mmx165mmx50mm(6.5”x6.5”x1.97”)Installation Wall mountColor WhiteSafety StandardsCertification CE(EN55032, EN55020)FCC(FCC Part 15 Class B, ISED ICES-003 Issue 6) Ordering InformationType Part Number DescriptionPower seriesDH-PFM340-5CH CCTV distributed power supply_Dahua brand, 5x0.8A, DC12VDH-PFM341-9CH CCTV distributed power supply_Dahua brand, 9x0.55A, DC12VDH-PFM342-9CH CCTV distributed power supply_Dahua brand, 9x1.1A, DC12VDH-PFM343-19CH CCTV distributed power supply_Dahua brand, 19x1.05A, DC12V

Lees meer minder

Dahua, voeding voor muurmontage, AC90-264V input, DC12V 20A 19CH output DH-PFM343-19CH CCTV Distributed Power Supply Box  Features· 19 Channel security camera power supply distribution box with individual LED output indicator and metal case by lockkey to prevent unauthorized access;· Wide voltage input: AC90~264Vac, meet the requirements in different parts for electric network fluctuation;· High quality and reliability: pass 100% quality examination and 3 months high temperature aging test;· With overload protection, over-current protection, over-voltage protection, anti-static and anti-interference ability;· Professional wall-mounted installation with reserved outlet holes, convenient and flexible.  Technical SpecificationElectrical SpecificationModel DH-PFM343-19CHInput Voltage Range AC90~264VOutputs 19 x 12VDC (-3%~+7%) outputsMax. output 20A, 240WOutput Protection 19 replacement fuses, max. per output 3AEfficiency 87%No Load Power Consumption <0.21WInternal ON/OFF Power Switch YesIndividual LED Output Indicator YesProtection/EnvironmentalSurge Protected Line to ground: 4000VLine to line: 2000VESD Contact discharge: 6000VAir discharge: 8000VWorking Temperature -20℃~+45℃(-4℉~+113℉)Working Humidity <90% RHPhysical PropertiesWeight 2.52kg(5.56lb)Dimension(LxWxH) 315mmx215mmx53mm (12.4”x8.46”x2.09”)Installation Wall mountColor WhiteSafety StandardsCertification CE(EN55032, EN55020)FCC(FCC Part 15 Class B, ISED ICES-003 Issue 6) Ordering InformationType Part Number DescriptionPower seriesDH-PFM340-5CH CCTV distributed power supply_Dahua brand, 5x0.8A, DC12VDH-PFM341-9CH CCTV distributed power supply_Dahua brand, 9x0.55A, DC12VDH-PFM342-9CH CCTV distributed power supply_Dahua brand, 9x1.1A, DC12VDH-PFM343-19CH CCTV distributed power supply_Dahua brand, 19x1.05A, DC12V

Lees meer minder
